canal实现从mysql实时同步数据到es

2022-07-15 16:23:00 【浅唱~幸福】

1.环境准备：

1.1 mysql:5.7

1.2 elasticsearch:7.4.2

1.3 kibana:7.4.2

1.4 服务端：canal-deployer1.1.5

1.5 客户端：canal-adapter 1.1.5

2.下载安装MySQL（注：本人项目都是docker安装这里就不一一展示安装步骤了详情见百度或者看我其他文章）修改mysql配置文件开启binlog日志,并且以ROW方式,开启主从模式以及logbin的文件位置如下：

server_id=101
binlog-ignore-db=mysql
log-bin=mall-mysql-bin
binlog_cache_size=1M
binlog_format=row
expire_logs_days=7
slave_skip_errors=1062

2.1 记得重启下mysql 查看MySQL配置是否开启

SHOW VARIABLES LIKE 'binlog-format'; -- 结果应该是ROW
SHOW VARIABLES LIKE 'log_bin'; -- 结果应该是 ON
SHOW VARIABLES LIKE '%log%'; -- 所有binlog信息

2.2 然后给canal创建一个canal账户命令如下：

CREATE USER canal IDENTIFIED BY 'canal';
GRANT SELECT, REPLICATION SLAVE, REPLICATION CLIENT ON *.* TO 'canal'@'%';
FLUSH PRIVILEGES;

2.3 创建一个canal-test库和sys_log测试表

DROP TABLE IF EXISTS `sys_log`;
CREATE TABLE `sys_log` (
`id` varchar(64) CHARACTER SET utf8 COLLATE utf8_general_ci NOT NULL COMMENT '编号',
`type` char(1) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT '1' COMMENT '日志类型',
`title` varchar(255) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT '' COMMENT '日志标题',
`create_by` varchar(64) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL COMMENT '创建者',
`create_date` datetime NULL DEFAULT NULL COMMENT '创建时间',
`remote_addr` varchar(255) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL COMMENT '操作IP地址',
`user_agent` varchar(255) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL COMMENT '用户代理',
`request_uri` varchar(255) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL COMMENT '请求URI',
`method` varchar(5) CHARACTER SET utf8 COLLATE utf8_general_ci NULL DEFAULT NULL COMMENT '操作方式',
`params` text CHARACTER SET utf8 COLLATE utf8_general_ci NULL COMMENT '操作提交的数据',
`exception` text CHARACTER SET utf8 COLLATE utf8_general_ci NULL COMMENT '异常信息',
PRIMARY KEY (`id`) USING BTREE
) ENGINE = InnoDB CHARACTER SET = utf8 COLLATE = utf8_general_ci COMMENT = '日志表' ROW_FORMAT = Dynamic;

3.下载安装ES和Kibana 这里需要注意的是两个版本需要一致这里就不介绍了如下我自己安装的：

4.下载canal 的服务器端 canal-deployer1.1.5 和客户端 canal-adapter 1.1.5 下载地址为：https://github.com/alibaba/canal/releases

5. 解压这两个项目命令：

tar -zxvf canal.adapter-1.1.5.tar.gz

tar -zxvf canal.deployer-1.1.5.tar.gz

6.修改服务端 canal.deployer-1.1.5下conf目录名example为orgdeer-cui 命令：mv example orgdeer-cui 然后修改配置conf/orgdeer-cui/instance.properties 主要是修改数据库相关配置改下面三个地方如下：

6.启动服务器端canal.deployer-1.1.5

切换目录：cd /home/canal/canal.deployer-1.1.5/bin

启动：./startup.sh

7.查看日志是否启动成功：

tail -f /home/canal/canal.deployer-1.1.5/logs/canal/canal.log

8. 修改客户端 canal.adapter-1.1.5下的配置 application.yml 主要是修改canal-server配置、数据源配置和客户端适配器配置主要改一下带注释的部分如下：

server:
port: 8081
logging:
level:
com.alibaba.otter.canal.client.adapter.es: DEBUG
spring:
jackson:
date-format: yyyy-MM-dd HH:mm:ss
time-zone: GMT+8
default-property-inclusion: non_null

canal.conf:
mode: tcp #tcp kafka rocketMQ rabbitMQ
flatMessage: true
zookeeperHosts:
syncBatchSize: 1000
# IMPORTANT!!! KEEP ADAPER SYNC CONSISTANT
retries: -1
timeout:
accessKey:
secretKey:
consumerProperties:
# canal tcp consumer
canal.tcp.server.host: 127.0.0.1:11111 #服务器端地址
canal.tcp.zookeeper.hosts:
canal.tcp.batch.size: 500
canal.tcp.username:
canal.tcp.password:
# kafka consumer
kafka.bootstrap.servers: 127.0.0.1:9092
kafka.enable.auto.commit: false
kafka.auto.commit.interval.ms: 1000
kafka.auto.offset.reset: latest
kafka.request.timeout.ms: 40000
kafka.session.timeout.ms: 30000
kafka.isolation.level: read_committed
kafka.max.poll.records: 1000
# rocketMQ consumer
rocketmq.namespace:
rocketmq.namesrv.addr: 127.0.0.1:9876
rocketmq.batch.size: 1000
rocketmq.enable.message.trace: false
rocketmq.customized.trace.topic:
rocketmq.access.channel:
rocketmq.subscribe.filter:
# rabbitMQ consumer
rabbitmq.host:
rabbitmq.virtual.host:
rabbitmq.username:
rabbitmq.password:
rabbitmq.resource.ownerId:

srcDataSources:
defaultDS:
url: jdbc:mysql://127.0.0.1:3306/canal-test?useUnicode=true&characterEncoding=UTF-8&serverTimezone=GMT%2B8&useSSL=false&useInformationSchema=false&allowPublicKeyRetrieval=true #mysql链接地址
username: root #用户名
password: hzp123456 #密码
canalAdapters:
- instance: orgdeer-cui # 对应的是服务器端中配置mq topic name
groups:
- groupId: g1
outerAdapters:
- name: logger #日志打印适配器
- name: es7 #ES同步适配器
hosts: 127.0.0.1:9300 #ESl链接地址
properties:
mode: transport #模式可选transport（9300）或者rest(9200)
cluster.name: elasticsearch #ES集群名称
HOSTNAME%%.*:
PWD/#$HOME/~:

9.启动客户端 canal.adapter-1.1.5

切换目录：cd /home/canal/canal.adapter-1.1.5/bin

启动：./startup.sh

10 查看客户端日志是否启动成功

tail -f /home/canal/canal.adapter-1.1.5/logs/adapter/adapter.log

11.添加配置文件canal-adapter/conf/es7/sys_log.yml，用于配置MySQL中的表与Elasticsearch中索引的映射关系（注意destination名称orgdeer-cui要跟服务器端mq topic name对应）然后将文件sys_log.yml放到/home/canal/canal.adapter-1.1.5/conf/es7目录下

dataSourceKey: defaultDS
destination: orgdeer-cui
groupId: g1
esMapping:
  _index: sys_log
  _id: _id
  sql: "select
        id as _id, type,
         title,
         create_by as createBy,
         UNIX_TIMESTAMP(create_date) as createDate,
        remote_addr as remoteAddr,
        user_agent as userAgent,
        request_uri as requestUri,method,
        params,exception
        from sys_log"
  etlCondition: "where create_date>={}"
  commitBatch: 3000

12.在Kibana控制台中创建sys_log索引

PUT sys_log
{
"mappings": {
"properties":{
"type":{
"type":"keyword"
},
"title":{
"type":"text"
},
"createBy":{
"type":"keyword"
},
"remoteAddr":{
"type": "text"
},
"userAgent":{
"type":"text"
},
"requestUri": {
"type": "text"
},
"method": {
"type": "keyword"
},
"params": {
"type": "text"
},
"exception": {
"type": "text"
},
"createDate": {
"type": "long"
}
}
}
}
