Qimage image format summary

Um. , This QImage For a long time , It didn't work for a while , Forget , I've been asked twice , All of a sudden, I can't explain it clearly , I'm ashamed , I think it's necessary to sum it up again , Otherwise, I will be shameless to myself .

The image data is saved in bytes , The number of bytes per line must be 4 Integer multiple , The lack of fill 0.

（ Because we're using 32 operating system , So the data is based on 32 Bit aligned , So the number of bytes per line must be 4 That is, the data bits of each row must be 32 Integer multiple of bits .） Here is according to my understanding , It seems wrong , Fix it , I've been looking at data alignment recently , This passage ignores , Not deleted , Because , Want to leave a footprint , I'll post it when I find the right answer . however , The data of the image is indeed according to 32 Bit aligned .

If it's not an integer multiple , According to the formula ： W = ( w * bitcount + 31 )/32 * 4;

notes ：  w Is the width of the image ,bitcount Is the bit depth of the image , namely 32、24 etc. , Calculated W Is the number of bytes per line of the image in the program .

Here's the story QImage Of 32、24、8 Bitmap .

Image format :QImage::Format_RGB32 ,QImage::Format_RGB888,QImage::Format_Indexed8.

Construct an image ：

    (1)、QImage myImage1 = QImage(filename);   Open the image according to the file name , If the image itself is 32、24 Bit , The image in the program is 32 Bit , If the image itself is 8 position 、1 Bit , The program corresponds to 8 position 、1 position .

   (2)、QImage myImage2 = QImage(width, height, QImage::Format_…); Construct an image according to the width and height of the image , The program will automatically align the image data according to the image format .

Manipulating images ： according to (2) Construct the image in a way , stay Debug Next , If you don't give the image myImage2 initial value , The image is not black , but release Next , The constructed image defaults to black .

Okay , Now we need to operate on image data ,32 Bit images are undoubtedly the simplest , Because its data is aligned . use width Represents the width of the image ,height Represents the height of the image .

First, be familiar with a few functions ：

a、uchar* bits();        You can get the first address of the image

b、int  byteCount();   The total number of bytes of the image

c、int  bytesPerLine(); Number of bytes per line

1、QImage::Format_RGB32, The deposit format is B,G,R,A Corresponding 0,1,2,3

    QImage::Format_RGB888, The deposit format is R, G, B Corresponding 0,1,2

    QImage::Format_Indexed8, You need to set the color table ,QVector<QRgb>

     Gray image color table setting ：

    QVector<QRgb>  colorTable;

    for(int k=0;k<256;++k)
    {

           colorTable.push_back( qRgb(k,k,k) );

    }

2、QImage  p_w_picpath32 = QImage(width, height, QImage::Format_32);

     QImage  p_w_picpath24 = QImage(width, height, QImage::Format_24);

     QImage  p_w_picpath8 = QImage(width, height, QImage::Format_8);

     p_w_picpath8.setColorTable(colorTable);

3、 Need to take each pixel for processing , Use pointer value , The way of line scanning ：

    int  lineNum_32 = 0;     // Row number

    int  pixelsub_32 = 0;    // Pixel subscript

    uchar*    p_w_picpathbits_32 = p_w_picpath32.bits();         // Get the first address of the image ,32 Bitmap

    uchar*    p_w_picpathbits24 = p_w_picpath24.bits();

    uchar*    p_w_picpathbits8 = p_w_picpath8.bits();

    for(int i=0; i<height; ++i)

    {

           // According to the usual understanding , We will deal with it as follows , Take each line

           lineNum_32 = i * width * 4;                  // For any image , There is no problem with this sentence

           // lineNum_24 = i * width * 3;             //？？ When width No 4 The integral times of , This sentence doesn't start on every line

           // lineNum_8 = i * width;                 //？？ When width No 4 The integral times of , This sentence doesn't start on every line

         for(int j=0; j<width; ++j)

         {

               int r_32 = p_w_picpathbits_32[ lineNum_32 + j * 4 + 2];

               int g_32 = p_w_picpathbits_32[ lineNum_32 + j * 4 + 1];

               int b_32 = p_w_picpathbits_32[ lineNum _32 + j * 4];

               // int r_24 = p_w_picpathbits_24[ lineNum_24 + j * 3];        // Pay attention to differences 32 Bit graph

               // int g_24 = p_w_picpathbits_24[ lineNum_24 + j *3 + 1];

               // int b_24 = p_w_picpathbits_24[ lineNum_24 + j * 3 + 2];

               // int gray_8 = p_w_picpathbits_8[ lineNum_8 + j];

               ……

               // My own operation

         }

    }

//？？ Something is wrong. , Because the actual image data is not based on width Is of true width , solve , There are two ways ：

The first method ： Calculate the actual width by yourself

It is amended as follows ：

// Get the number of bytes per line

int  W_32 = ( width * 32 + 31 )/32 * 4;           // Note that there is no rounding here , So don't convert at will

int  W_24 = ( width * 24 + 31 )/32 * 4;

int  W_8 = ( width * 8 + 31)/32 * 4;

       // You can also use QT Function to get , The function is the same as above

{

        int  W_32 = p_w_picpath32.bytesPerLine();

        int  W_24 = p_w_picpath24.bytesPerLine();

        int  W_8 = p_w_picpath8.bytesPerLine();

}

for(int i=0;  i<height;  ++i)

{

           // Now we can follow the usual understanding , Take each line

           lineNum_32 = i * W_32;               // Be careful , There's no need to multiply here (4, 3 etc. )

           // lineNum_24 = i * W_24;

           // lineNum_8 = i * W_8;

         for(int j=0; j<width; ++j)

         {

               // The operation here is the same as that above

         }

}

The second method ： use scanLine(int) To get the first address of each line ,

for(int i=0; i<height; ++i)

{

       p_w_picpathbits_32 = p_w_picpath32.scanLine(i);

       p_w_picpathbits_24 = p_w_picpath24.scanLine(i);

       p_w_picpathbits_8 = p_w_picpath8.scanLine(i);

       for(int j=0; j<width; ++j)

      {

               int r_32 = p_w_picpathbits_32[ j * 4 + 2];

               int g_32 = p_w_picpathbits_32[ j * 4 + 1];

               int b_32 = p_w_picpathbits_32[ j * 4];

               // int r_24 = p_w_picpathbits_24[ j * 3];

               // int g_24 = p_w_picpathbits_24[ j *3 + 1];

               // int b_24 = p_w_picpathbits_24[ j * 3 + 2];

               // int gray_8 = p_w_picpathbits_8[ j ];

               ……

               // My own operation

      }

}

OK, The index of the above two methods will not have the problem of image data offset

4、 Notice that QImage The constructor of ,QImage::QImage ( uchar * data, int width, int height, Format format )

      Um. , This function starts from uchar* To construct an image , Generally, we may store the image data first uchar* in ,

     uchar* data32 = new uchar[ width * height * 4];

     uchar* data24 = new uchar[ width * height * 3];

     uchar* data8 = new uchar[ width * height];

      from data32 Construct an image , There will be no problem , But when width No 4 The integral times of , You can't start from data24 and data8 Construct the data you want , The program will hang up , Because the data volume of these two arrays is not enough for one picture at all （ Remember if the data is complete ）.

terms of settlement ：

You need to first calculate , The amount of real data in your image ( Number of bytes ), According to QImage.byteCount() Function to get the number of bytes of the image , Of course , You can also calculate by yourself , Calculation formula byteCount = height * W;    there W Is the number of bytes per line , Its calculation method has been described above .

then , You can choose from QByteArray To get the converted pointer data ：

Such as ： Put your image data in an array   uchar*  srcData;   in

QByteArray p_w_picpathByteArray = QByteArray( (const char*)srcData,  byteCount );

uchar*  transData = (unsigned char*)p_w_picpathByteArray.data();

QImage desImage = QImage(transData, width, height, QImage::Format_…);

Um. , After the above conversion ,transData Will be an array of complementary data , The image thus constructed will not have any problems .

Okay , It's over , There are many small problems , I don't want to write , It should be enough , If you have specific other questions , Think again , It must be solved , ha-ha
