1. Basic model of illumination

stay OpenGL ES 2.X Lighting model used in （ passageway ） branch 3 Kind of ： The ambient light 、 Scattered light and Specular light .

1.1 The ambient light

The ambient light (Ambient) It refers to irradiating an object from all directions , comprehensive 360° Uniform light .

Mathematical model formula ：

$$Ambient\; light\; exposure\; results=Reflection\; coefficient\; of\; material\ast Ambient\; light\; intensity$$

Complete code of vertex shader and slice shader in ambient light ：

vertex.sh

uniform mat4 uMVPMatrix;// Total transformation matrix
attribute vec3 aPosition;// Vertex Position
varying vec3 vPosition;// Vertex position passed to the slice shader
varying vec4 vAmbient;// The ambient light component passed to the slice shader

void main(){
    gl_Position = uMVPMatrix * vec4(aPosition,1);
    vPosition = aPosition;
    vAmbient = vec4(0.15,0.15,0.15,1.0);
}

frag.sh

precision mediump float;
uniform float uR;// The sphere
varying vec3 vPosition;// Vertex shader passed
varying vec4 vAmbient;// The intensity of the ambient light passed by the vertex shader
void main(){
  vec3 color;
  float n = 8.0;
  float span = 2.0*uR/n;
  int i = int((vPosition.x + uR)/span);
  int j = int((vPosition.y + uR)/span);
  int k = int((vPosition.z + uR)/span);

  int whichColor = int(mod(float(i+j+k),2.0));
  if(whichColor==1){
      color = vec3(0.678,0.231,0.129);
    }else{
      color = vec3(1.0,1.0,1.0);
    }
    vec4 finalColor = vec4(color,0);
    gl_FragColor = finalColor * vAmbient;
}

【 Description of ambient light 】

• Ambient light has no directionality ;
• The illumination effect of ambient light is independent of the position of the light source （ Look at the following GIF chart ）;
• In actual development, the ambient light intensity is generally set to be weak ;

1.2 Scattered light

Scattered light (Diffuse), It refers to all directions from the surface of the object 360° Uniformly reflected light .

Mathematical model formula ：

$$\begin{gathered} Final\; intensity\; of\; scattered\; light=Scattered\; light\; intensity\ast max(cos(Angle\; of\; incidence),0) \\ Scattered\; light\; irradiation\; results=Reflection\; coefficient\; of\; material\ast Final\; intensity\; of\; scattered\; light \end{gathered}$$

• Reflection coefficient of material ： The color of the object being illuminated ;
• Scattered light intensity ： In scattered light RGB3 Color channel intensity

Complete code of vertex shader and slice shader under scattered light ：

vertex.sh

uniform mat4 uMVPMatrix;
uniform mat4 uMMatrix;
uniform vec3 uLightLocation;
attribute vec3 aPosition;
attribute vec3 aNormal;
varying vec3 vPosition;
varying vec4 vDiffuse;// The scattered light component used to pass to the slice shader

void pointLight(in vec3 normal,inout vec4 diffuse,in vec3 lightLocation,in vec4 lightDiffuse){
  vec3 normalTarget = aPosition + normal;
  vec3 newNormal = (uMMatrix*vec4(normalTarget,1)).xyz - (uMMatrix*vec4(aPosition,1)).xyz;
  newNormal = normalize(newNormal);

  vec3 vp = normalize(lightLocation-(uMMatrix*vec4(aPosition,1)).xyz);
  vp = normalize(vp);
  float nDotViewPosition=max(0.0,dot(newNormal,vp));

  diffuse = lightDiffuse * nDotViewPosition;
}

void main(){
    gl_Position = uMVPMatrix * vec4(aPosition,1);
    vec4 diffuseTemp = vec4(0.0,0.0,0.0,0.0);
    pointLight(normalize(aNormal),diffuseTemp,uLightLocation,vec4(0.8,0.8,0.8,1.0));
    vDiffuse = diffuseTemp;
    vPosition = aPosition;
}

frag.sh

precision mediump float;
uniform float uR;
varying vec3 vPosition;
varying vec4 vDiffuse;// Receive the final intensity of scattered light transmitted from the vertex
void main(){
  vec3 color;
  float n = 8.0;
  float span = 2.0*uR/n;
  int i = int((vPosition.x + uR)/span);
  int j = int((vPosition.y + uR)/span);
  int k = int((vPosition.z + uR)/span);

  int whichColor = int(mod(float(i+j+k),2.0));
  if(whichColor==1){
      color = vec3(0.678,0.231,0.129);
    }else{
      color = vec3(1.0,1.0,1.0);
    }
    vec4 finalColor = vec4(color,0);
    gl_FragColor = finalColor * vDiffuse;
}

【 Scattered light description 】

• Scattered light , It can also be called diffuse reflection ;
• The reflected backscattered light is uniform in all directions ;
• The intensity of scattered light reflection is closely related to the intensity and angle of incident light , The larger the incident angle , The weaker the reflection intensity ( Look down GIF chart );

1.3 Specular light

Specular light (Specular), The reflected light concentrated in the direction when the smooth surface is illuminated .

Mathematical model formula ：
$$\begin{gathered} Final\; intensity\; of\; specular\; light=Specular\; light\; intensity\ast max(0,(cos(The\; angle\; between\; half\; vector\; and\; normal\; vector))Roughness) \\ Specular\; light\; irradiation\; results=Reflection\; coefficient\; of\; material\ast Final\; intensity\; of\; specular\; light \end{gathered}$$

Complete code of vertex shader and slice shader under specular light ：

vertex.sh

uniform mat4 uMVPMatrix;
uniform mat4 uMMatrix;
uniform vec3 uLightLocation;
uniform vec3 uCamera;
attribute vec3 aPosition;
attribute vec3 aNormal;
varying vec3 vPosition;
varying vec4 vSpecular;

void pointLight(in vec3 normal,inout vec4 specular,in vec3 lightLocation,in vec4 lightSpecular){
  vec3 normalTarget = aPosition + normal;
  vec3 newNormal = (uMMatrix*vec4(normalTarget,1)).xyz - (uMMatrix*vec4(aPosition,1)).xyz;
  newNormal = normalize(newNormal);

  vec3 eye = normalize(uCamera-(uMMatrix*vec4(aPosition,1)).xyz);
  vec3 vp = normalize(lightLocation-(uMMatrix*vec4(aPosition,1)).xyz);
  vp = normalize(vp);
  vec3 halfVector = normalize(vp+eye);
  float shininess = 50.0;
  float nDotViewHalfVector=dot(newNormal,halfVector);
  float powerFactor = max(0.0,pow(nDotViewHalfVector,shininess));
  specular = lightSpecular*powerFactor;
}

void main(){
    gl_Position = uMVPMatrix * vec4(aPosition,1);
    vec4 specularTemp = vec4(0.0,0.0,0.0,0.0);
    pointLight(normalize(aNormal),specularTemp,uLightLocation,vec4(0.7,0.7,0.7,1.0));
    vSpecular = specularTemp;
    vPosition = aPosition;
}

frag.sh

precision mediump float;
uniform float uR;
varying vec3 vPosition;
varying vec4 vSpecular;
void main(){
  vec3 color;
  float n = 8.0;
  float span = 2.0*uR/n;
  int i = int((vPosition.x + uR)/span);
  int j = int((vPosition.y + uR)/span);
  int k = int((vPosition.z + uR)/span);

  int whichColor = int(mod(float(i+j+k),2.0));
  if(whichColor==1){
      color = vec3(0.678,0.231,0.129);
    }else{
      color = vec3(1.0,1.0,1.0);
    }
    vec4 finalColor = vec4(color,0);
    gl_FragColor = finalColor * vSpecular;
}

【 Specular light description 】

• The intensity of specular light depends on the angle between the incident light and the normal vector of the illuminated point 、 Observer position ;
• The less roughness , The larger the area of mirror light
• The specular light changes with the position of the light source




The effect of mixing the three lights GIF

Case source code download

Ambient light effect Demo
Scattered light effect Demo
Specular effect Demo
