Ten optimization rules of Clickhouse SQL

as everyone knows ,ClickHouse  Of SQL The optimization rules are based on RBO(Rule Based Optimization) Of , So do you know the optimization rules  ？

What's next , It's the ten optimization rules I sorted out at the end of last year , Not necessarily all. , It's just for throwing bricks and attracting jade . If you have any additional information , Welcome to write to me .

1. COUNT Optimize  :

Calling count Function time , If you are using count() perhaps count(*), And there's no where Conditions , It will be used directly  system.tables Of total_rows, for example :

EXPLAIN
SELECT count()
FROM test_x


Query id: d255fb14-7160-4f1a-9148-9810494d792d


┌─explain──────────────────────────────────────────────┐
│ Expression ((Projection + Before ORDER BY))          │
│   MergingAggregated                                  │
│     ReadFromPreparedSource (Optimized trivial count) │
└──────────────────────────────────────────────────────┘

Be careful  Optimized trivial count , That's right count The optimization of the .

If count Specific column fields , This optimization will not be used ：

EXPLAIN
SELECT count(id)
FROM test_x


Query id: 170b10db-88d7-45a1-ae8a-8d683707b635


┌─explain───────────────────────────────────────────────────────────────────────┐
│ Expression ((Projection + Before ORDER BY))                                   │
│   Aggregating                                                                 │
│     Expression (Before GROUP BY)                                              │
│       SettingQuotaAndLimits (Set limits and quota after reading from storage) │
│         ReadFromStorage (MergeTree)                                           │
└───────────────────────────────────────────────────────────────────────────────┘

2. Eliminate duplicate fields in subqueries :

There are two repetitions in the following sentence query id Field , It's going to be removed :

EXPLAIN SYNTAX
SELECT
    a.id,
    b.name,
    a.price,
    b.id
FROM id_join_tb1 AS a
LEFT JOIN
(
    SELECT
        id,
        id,
        name,
        time
    FROM join_tb1
) AS b USING (id)


Query id: 6879ecc6-8579-4f01-964c-9eab4b15687a


┌─explain───────────────┐
│ SELECT                │
│     id,               │
│     name,             │
│     price,            │
│     b.id              │
│ FROM id_join_tb1 AS a │
│ ALL LEFT JOIN         │
│ (                     │
│     SELECT            │
│         id,           │
│         name          │
│     FROM join_tb1     │
│ ) AS b USING (id)     │
└───────────────────────┘

3. Predicate push-down :

When group by Yes having Clause , But no  with cube、with rollup perhaps with totals When decorating ,having  The filter will be pushed down to where Filtering ahead of time . For example, the following query ,HAVING name Turned into WHERE name, stay group by Before filtering :

EXPLAIN SYNTAX
SELECT name
FROM join_tb1
GROUP BY name
HAVING name = ''


Query id: 6eb2f8eb-2e29-43ae-9414-5914b921a622


┌─explain─────────┐
│ SELECT name     │
│ FROM join_tb1   │
│ WHERE name = '' │
│ GROUP BY name   │
└─────────────────┘

alike , Subqueries also support predicate push down , For example, the  WHERE id = 10:

EXPLAIN SYNTAX
SELECT *
FROM
(
    SELECT id
    FROM id_join_tb1
)
WHERE id = 10


Query id: 44a3e084-4b8a-4847-9909-ec34c8d8be74


┌─explain──────────────┐
│ SELECT id            │
│ FROM                 │
│ (                    │
│     SELECT id        │
│     FROM id_join_tb1 │
│     WHERE id = 10    │
│ )                    │
│ WHERE id = 10        │
└──────────────────────┘

Let's do another example :

EXPLAIN SYNTAX
SELECT *
FROM
(
    SELECT *
    FROM
    (
        SELECT id
        FROM id_join_tb1
    )
    UNION ALL
    SELECT *
    FROM
    (
        SELECT id
        FROM id_join_tb1
    )
)
WHERE id = 10


Query id: a807c968-a4b9-4f84-a80d-48c8385d2206


┌─explain──────────────────┐
│ SELECT id                │
│ FROM                     │
│ (                        │
│     SELECT id            │
│     FROM                 │
│     (                    │
│         SELECT id        │
│         FROM id_join_tb1 │
│         WHERE id = 10    │
│     )                    │
│     WHERE id = 10        │
│     UNION ALL            │
│     SELECT id            │
│     FROM                 │
│     (                    │
│         SELECT id        │
│         FROM id_join_tb1 │
│         WHERE id = 10    │
│     )                    │
│     WHERE id = 10        │
│ )                        │
│ WHERE id = 10            │
└──────────────────────────┘

4. Aggregate computing extrapolation :

Calculations in aggregate functions , Will extrapolate , for example ：

EXPLAIN SYNTAX
SELECT sum(id * 2)
FROM join_tb1


Query id: 027a5dce-fa57-447a-9615-888881069d61


┌─explain────────────┐
│ SELECT sum(id) * 2 │
│ FROM join_tb1      │
└────────────────────┘

5. Aggregate functions eliminate :

If you want to aggregate bonds , That is to say group by key Use  min、max、any Aggregate functions , Then the function is eliminated , for example ：

EXPLAIN SYNTAX
SELECT
    sum(id * 2),
    max(name),
    max(id)
FROM join_tb1
GROUP BY id


Query id: 4d72f7fa-5146-4365-adc4-260566f5f414


┌─explain──────────┐
│ SELECT           │
│     sum(id) * 2, │
│     max(name),   │
│     id           │
│ FROM join_tb1    │
│ GROUP BY id      │
└──────────────────┘

6. Delete duplicate group by key

For example, the following statement , Repeated aggregation bonds id Fields will be de duplicated :

EXPLAIN SYNTAX
SELECT *
FROM join_tb1
ORDER BY
    id ASC,
    id ASC,
    name ASC,
    name ASC


Query id: 3fc0267a-9bf7-4811-b384-4a9e90517bbf


┌─explain───────┐
│ SELECT        │
│     id,       │
│     name,     │
│     time      │
│ FROM join_tb1 │
│ ORDER BY      │
│     id ASC,   │
│     name ASC  │
└───────────────┘

7. Delete duplicate limit by key

For example, the following statement , Repeated statement of name Fields will be de duplicated :

EXPLAIN SYNTAX
SELECT *
FROM join_tb1
LIMIT 3 BY
    name,
    name
LIMIT 10


Query id: e87a0ed9-66b4-49c7-b6ea-b5c8ad3d7901


┌─explain─────────┐
│ SELECT          │
│     id,         │
│     name,       │
│     time        │
│ FROM join_tb1   │
│ LIMIT 3 BY name │
│ LIMIT 10        │
└─────────────────┘

8. Delete duplicate USING Key

For example, the following statement , Duplicate Association keys id Fields will be de duplicated :

EXPLAIN SYNTAX
SELECT
    a.id,
    a.id,
    b.name,
    a.price,
    b.id
FROM id_join_tb1 AS a
LEFT JOIN join_tb1 AS b USING (id, id)


Query id: d0917046-71da-469e-b738-14d947bf53e3


┌─explain────────────────────────────────┐
│ SELECT                                 │
│     id,                                │
│     id,                                │
│     name,                              │
│     price,                             │
│     b.id                               │
│ FROM id_join_tb1 AS a                  │
│ ALL LEFT JOIN join_tb1 AS b USING (id) │
└────────────────────────────────────────┘

9. Scalar substitution

If a subquery returns only one row of data , Replace with scalar when referenced , For example, in the following statement  total_disk_usage Field :

EXPLAIN SYNTAX
WITH
    (
        SELECT sum(bytes)
        FROM system.parts
        WHERE active
    ) AS total_disk_usage
SELECT
    (sum(bytes) / total_disk_usage) * 100 AS table_disk_usage,
    table
FROM system.parts
GROUP BY table
ORDER BY table_disk_usage DESC
LIMIT 10


Query id: a9c7431f-cd51-4a85-9fba-b6301578a8cd


┌─explain────────────────────────────────────────────────────────┐
│ WITH identity(CAST(0, 'UInt64')) AS total_disk_usage           │
│ SELECT                                                         │
│     (sum(bytes) / total_disk_usage) * 100 AS table_disk_usage, │
│     table                                                      │
│ FROM system.parts                                              │
│ GROUP BY table                                                 │
│ ORDER BY table_disk_usage DESC                                 │
│ LIMIT 10                                                       │
└────────────────────────────────────────────────────────────────┘

10. Ternary optimization

If it's on  optimize_if_chain_to_multiif Parameters , The ternary operator will be replaced with  multiIf function , for example :

EXPLAIN SYNTAX
SELECT number = 1 ? 'hello' : (number = 2 ? 'world' : 'xyz')
FROM numbers(10)
settings optimize_if_chain_to_multiif = 1


Query id: fd5cde0f-a73f-4763-b823-42f9367f658b


┌─explain─────────────────────────────────────────────────────────┐
│ SELECT multiIf(number = 1, 'hello', number = 2, 'world', 'xyz') │
│ FROM numbers(10)                                                │
│ SETTINGS optimize_if_chain_to_multiif = 1                       │
└─────────────────────────────────────────────────────────────────┘

You have all these rules Get Have we arrived ?

author ： Zhu Kai ,ClickHouse One of the contributors ,ClickHouse evangelist , Senior architect ,《ClickHouse Principle analysis and practical application 》《 Enterprise level big data platform construction ： Architecture and implementation 》 author ,

More than a decade IT Employment experience , Have in-depth research on mainstream technologies and solutions in the field of big data , Good at architecture design and integration of distributed system . He has led the planning of many big data platform level products 、 Design and R & D work , Rich experience in front line combat .
