Mux256to1v,Hadd,Fadd
2022-07-19 09:35:00 【Shanghai style sweetheart】
Create a 4-bit wide, 256-to-1 multiplexer. The 256 4-bit inputs are all packed into a single 1024-bit input vector. sel=0 should select bits in[3:0], sel=1 selects bits in[7:4], sel=2 selects bits in[11:8], etc.
There are several ways
module top_module(
input [1023:0] in,
input [7:0] sel,
output [3:0] out );
assign out = {in[sel*4+3], in[sel*4+2], in[sel*4+1], in[sel*4+0]};
endmodulemodule top_module(
input [1023:0] in,
input [7:0] sel,
output [3:0] out );
assign out = in[sel*4 +: 4];// from sel*4 Start , Select bit number greater than sel*4 Of 4 A bit , amount to [sel*4+3:sel*4]
endmodulemodule top_module(
input [1023:0] in,
input [7:0] sel,
output [3:0] out );
assign out = in[sel*4+3 -: 4]; // from sel*4+3 Start , Select bit number less than sel*4+3 Of 4 A bit , amount to [sel*4+3:sel*4]
endmoduleCreate a half adder. A half adder adds two bits (with no carry-in) and produces a sum and carry-out.
module top_module(
input a, b,
output cout, sum );
assign {cout,sum} = a + b;
endmodule
Create a full adder. A full adder adds three bits (including carry-in) and produces a sum and carry-out.
module top_module(
input a, b, cin,
output cout, sum );
assign{cout,sum} = a + b + cin;
endmodule
