Browser compatibility testing system, method and process

Browser compatibility test method , Include :
　　 step 1: Operate in the user interface , Upload test script or call history script ;
　　 step 2: The user selects the browser to test , The test system will be stored in Docker The corresponding image in the image module is called to the container management module ;
　　 step 3: The container management module starts in step 2 Planned in Docker image , And check the environment of the startup results ;
　　 step 4: The test system uploads the test script to the test system through the file management module , And call the browser in the container to test , And feed back the test progress in real time ;
　　 step 5: The test system obtains the test results through the result processing module , And feed it back to the user interface . Users can view through the interactive interface , Manage and download test results .
　　 According to another embodiment of the present invention , The above steps 3 It also includes the environmental detection of the startup results .
　　 According to another embodiment of the present invention , The above steps 4 It also includes storing test results .
　　 According to another embodiment of the present invention , The above result processing module obtains the test results from the storage .
　　 The browser compatibility test system and method of the invention utilize the browser compatibility test method based on Docker The operating environment is completely isolated from the outside world , Maintain data isolation and reduce the occupation of test resources , say concretely :
　　1） Effectively reduce the consumption of hardware resources . Improve resource utilization ;
　　2） Effectively isolate data interference and pollution in the same environment ;
　　3） Test scripts can be run in parallel in multiple environments , So as to improve the test efficiency .
　　 Specific implementation methods ：
　　 The invention is described in more detail below in combination with embodiments , However, the embodiment of the invention is not limited to this .
　　 Browser compatibility testing system includes :
　　 User interface , Used to enter user instructions , Upload test scripts , Manage historical scripts and historical test data , Realize interaction with users ;
　　 File management module , It is used to manage the upload script and upload it to the container of the deployment test environment ;
　　Docker Image module , Pre generated for storage container engine Docker image . Docker The image contains the test environment of the container started at run time , And the operation instructions of running the target test script when the container starts ;
　　 Container management module , It is used to manage and run the test environment of each tested browser Docker Mirror boot container , To run the target test script in the container's test environment , And realize the connection of the test terminal to the host to test the browser , Users can start multiple containers in parallel through this module for testing ;
　　 The result processing module is used to obtain the result file generated by the container in the process of running the test script , Analyze it and process it into a more readable test report , And feed it back to the user interface for display and download .
　　 Use Docker Container integration method , stay Docker Deploy the browser to be tested and the components required for script testing to form Docker Integrated test environment , Then upload test scripts and test commands through the interactive interface to conduct test operations .
　　 The test script includes : Command menu generation , Test data script, etc .
　　 The host deploys the test system and uses Docker Image to build a separate test environment .
　　 Users can manage test scripts through the front-end interactive interface , test result , Test data, etc .
　　 Browser compatibility test methods include :
　　 step 1: Operate on the user interface , Configure relevant test parameters , Upload scripts or call historical scripts to test ;
　　 step 2: The user selects the browser to test , The test system will be stored in Docker Corresponding in the image module Docker The image is called to the container management module in preparation for startup ;
　　 step 3: The container management module starts in step 2 Arranged in Docker image , And perform some environmental tests on the startup results , To ensure that the container is properly started for use by the test system ;
　　 step 4: The test system uploads the test script to Docker Containers , And call the browser in the container to test , Real time feedback of test progress , And store the test results
　　 step 5: The test system obtains the steps through the result processing module 4 Test results stored in , And feed back to the user interface , Users can view through the interactive interface , Manage and download test results .
　　 in summary , The test server of the invention obtains a pre generated container engine Docker Mirror image , This image contains the test environment of the container started at run time , And the operation instructions to start the target test script at run time . Container start up ; Mirror image , Start a container to run the target test script provided by the client through the interactive interface in the container test environment , To realize the automatic test of the browser to be tested ; After the test is completed , Get the process of the container running the target test script . The generated log file is used to analyze the test results of the application to be tested ; Last , The test system feeds back the test results and log data to the interactive interface , For display and download .
　　 be based on Docker The operating environment of is completely isolated from the outside world , The invention runs the automatic test script in the container , It not only realizes the test of the tested browser , It also ensures that the test script will not damage the file system of the host .
　　 Each embodiment in this specification focuses on differences from other embodiments , And the same or similar parts between the various embodiments can refer to each other . Mentioned in this manual “ One embodiment ”,“ Another embodiment ”,“ An embodiment ” And the like refer to specific features described in connection with the embodiments , The structure or characteristics are included in the general description of this application . An embodiment , The same expression appearing in multiple places in the specification does not necessarily refer to the same embodiment .
　　 Although the invention has been described with reference to a plurality of illustrative embodiments of the invention , But it should be understood , Those skilled in the art can design many other modifications and implementations , And these modifications and embodiments will fall within the scope of the present invention . The scope and spirit of the application disclosure principle .. More specifically , Within the scope of the disclosure and claims of this application , You can combine the components of the layout and / Or make various modifications and improvements to the layout . In addition to modifying and improving components and / Or outside the layout , Other uses are also obvious to those skilled in the art .
　　
