Micro, m3o micro service series (II)
2022-07-18 13:42:00 【Bai,】
micro Build blog
Make sure micro server Run in another terminal , And we have connected to it , That is, run the microserver
[[email protected] M3O]# micro server
2022-07-15 20:49:01 file=server/server.go:88 level=info Starting server
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering registry
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering broker
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering network
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering runtime
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering config
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering store
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering events
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering auth
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering proxy
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering api
2022-07-15 20:49:01 file=server/server.go:116 level=info Registering web
2022-07-15 20:49:01 file=server/server.go:206 level=info Starting server runtime
Check our local environment
[[email protected] ~]# micro env
* local 127.0.0.1:8081 Local running Micro Server
platform proxy.m3o.com Cloud hosted Micro Platform
If it's not the local environment , function
micro env set local
Create as a service item ：
[[email protected] ~]# micro new ports
Creating service ports
.
├── micro.mu
├── main.go
├── generate.go
├── handler
│ └── ports.go
├── proto
│ └── ports.proto
├── Dockerfile
├── Makefile
├── README.md
├── .gitignore
└── go.mod
download protoc zip packages (protoc-$VERSION-$PLATFORM.zip) and install:
visit https://github.com/protocolbuffers/protobuf/releases
compile the proto file ports.proto:
cd ports
make init
go mod vendor
make proto
[[email protected] ~]# ls ports
Dockerfile generate.go go.mod handler main.go Makefile micro.mu proto README.md
need 3 Methods ：
Save For blog insert and update
Query For reading and listing
Delete Delete
from ports Start ：
ports.proto:
syntax = "proto3";
//option go_package="./;posts";
package posts;
service Posts {
rpc Save(SaveRequest) returns (SaveResponse) {
}
rpc Query(QueryRequest) returns (QueryResponse) {
}
rpc Delete(DeleteRequest) returns (DeleteResponse) {
}
}
message SaveRequest {
string id = 1;
string title = 2;
string slug = 3;
string content = 4;
int64 timestamp = 5;
repeated string tags = 6;
}
message SaveResponse {
string id = 1;
}
message Post {
string id = 1;
string title = 2;
string slug = 3;
string content = 4;
int64 created = 5;
int64 updated = 6;
string author = 7;
repeated string tags = 8;
}
// Query posts. Acts as a listing when no id or slug provided.
// Gets a single post by id or slug if any of them provided.
message QueryRequest {
string id = 1;
string slug = 2;
string tag = 3;
int64 offset = 4;
int64 limit = 5;
}
message QueryResponse {
repeated Post posts = 1;
}
message DeleteRequest {
string id = 1;
}
message DeleteResponse {
}
Although we have defined Post Message type , But we still redefine some fields as the top-level fields of the message type SaveRequest. The main reason is that we don't want Dynamic command
If we embed Post post = 1 To SaveRequest, We will call the post service in the following ways ：
micro posts save --post_title=Title --post_content=Content
But we don't want to repeat post, Our first choice is ：
micro posts save --title=Title --content=Content
To rebuild proto, We have to make proto Issue the command in the project root directory .
Next to the main.go:
package main
import (
"posts/handler"
"github.com/micro/micro/v3/service"
"github.com/micro/micro/v3/service/logger"
)
func main() {
// Create the service
srv := service.New(
service.Name("posts"),
)
// Register Handler
srv.Handle(handler.NewPosts())
// Run service
if err := srv.Run(); err != nil {
logger.Fatal(err)
}
}
posts.go:
package handler
import (
"context"
"time"
"github.com/micro/dev/model"
"github.com/micro/go-micro/errors"
"github.com/micro/micro/v3/service/logger"
"github.com/micro/micro/v3/service/store"
proto "posts/proto"
"github.com/gosimple/slug"
)
type Posts struct {
db model.Model
idIndex model.Index
createdIndex model.Index
slugIndex model.Index
}
func NewPosts() *Posts {
createdIndex := model.ByEquality("created")
createdIndex.Order.Type = model.OrderTypeDesc
slugIndex := model.ByEquality("slug")
idIndex := model.ByEquality("id")
idIndex.Order.Type = model.OrderTypeUnordered
return &Posts{
db: model.New(
store.DefaultStore,
"posts",
model.Indexes(slugIndex, createdIndex),
&model.ModelOptions{
IdIndex: idIndex,
},
),
createdIndex: createdIndex,
slugIndex: slugIndex,
idIndex: idIndex,
}
}
func (p *Posts) Save(ctx context.Context, req *proto.SaveRequest, rsp *proto.SaveResponse) error {
logger.Info("Received Posts.Save request")
post := &proto.Post{
Id: req.Id,
Title: req.Title,
Content: req.Content,
Slug: req.Slug,
Created: time.Now().Unix(),
}
if req.Slug == "" {
post.Slug = slug.Make(req.Title)
}
return p.db.Save(post)
}
func (p *Posts) Query(ctx context.Context, req *proto.QueryRequest, rsp *proto.QueryResponse) error {
var q model.Query
if len(req.Slug) > 0 {
logger.Infof("Reading post by slug: %v", req.Slug)
q = p.slugIndex.ToQuery(req.Slug)
} else if len(req.Id) > 0 {
logger.Infof("Reading post by id: %v", req.Id)
q = p.idIndex.ToQuery(req.Id)
} else {
q = p.createdIndex.ToQuery(nil)
var limit uint
limit = 20
if req.Limit > 0 {
limit = uint(req.Limit)
}
q.Limit = int64(limit)
q.Offset = req.Offset
logger.Infof("Listing posts, offset: %v, limit: %v", req.Offset, limit)
}
posts := []*proto.Post{
}
err := p.db.List(q, &posts)
if err != nil {
return errors.BadRequest("proto.query.store-read", "Failed to read from store: %v", err.Error())
}
rsp.Posts = posts
return nil
}
func (p *Posts) Delete(ctx context.Context, req *proto.DeleteRequest, rsp *proto.DeleteResponse) error {
logger.Info("Received Post.Delete request")
return p.db.Delete(model.Equals("id", req.Id))
}
The above code uses Model Package. It sets the index , Enable us to query data , And tell the model to maintain these indexes .
1. need id Index can pass id Read
2. Need to create index , So when we list Posts , The order of posts will be descending according to the fields created
3. need slug Index can pass slug Read the post （ namely .myblog.com/post/awesome-post-url）
here micro run . Our post service should be deployed in the project root directory . Let's verify micro logs posts( The exact output may depend on the actual configuration format configuration )
Save post
func (p *Posts) Save(ctx context.Context, req *proto.SaveRequest, rsp *proto.SaveResponse) error {
logger.Info("Received Posts.Save request")
post := &proto.Post{
Id: req.Id,
Title: req.Title,
Content: req.Content,
Slug: req.Slug,
Created: time.Now().Unix(),
}
if req.Slug == "" {
post.Slug = slug.Make(req.Title)
}
return p.db.Save(post)
}
[[email protected] handler]# micro posts save --id=1 --title="Post one" --content="First saved post"
{
}
[[email protected] handler]# micro posts save --id=2 --title="Post two" --content="Second saved post"
{
}
Query posts
The query handler can pass id、slug Query and enable the post list
func (p *Posts) Query(ctx context.Context, req *proto.QueryRequest, rsp *proto.QueryResponse) error {
var q model.Query
if len(req.Slug) > 0 {
logger.Infof("Reading post by slug: %v", req.Slug)
q = p.slugIndex.ToQuery(req.Slug)
} else if len(req.Id) > 0 {
logger.Infof("Reading post by id: %v", req.Id)
q = p.idIndex.ToQuery(req.Id)
} else {
q = p.createdIndex.ToQuery(nil)
var limit uint
limit = 20
if req.Limit > 0 {
limit = uint(req.Limit)
}
q.Limit = int64(limit)
q.Offset = req.Offset
logger.Infof("Listing posts, offset: %v, limit: %v", req.Offset, limit)
}
posts := []*proto.Post{
}
err := p.db.List(q, &posts)
if err != nil {
return errors.BadRequest("proto.query.store-read", "Failed to read from store: %v", err.Error())
}
rsp.Posts = posts
return nil
}
( modify proto file , Or modify the code , Just make proto perhaps micro update .)
[[email protected] handler]# micro posts query
{
"posts": [
{
"id": "2",
"title": "Post two",
"slug": "post-two",
"content": "Second saved post",
"created": "1657894638"
},
{
"id": "1",
"title": "Post one",
"slug": "post-one",
"content": "First saved post",
"created": "1657894626"
}
]
}
Delete post
func (p *Posts) Delete(ctx context.Context, req *proto.DeleteRequest, rsp *proto.DeleteResponse) error {
logger.Info("Received Post.Delete request")
return p.db.Delete(model.Equals("id", req.Id))
}
Drop the complete project link ：https://github.com/micro/dev/tree/master/blog/v1-posts
