The practice of opengauss database on CentOS, configuration

Server preparation

use VM Install a virtual host locally , In the installation CentOS that will do .

The purpose of this experiment is to find out the potential problems , Gu eraser chose an off-site server , The configuration is as follows ：

1 CPU 2 GB / CentOS 7.6 64 position  / 40 GB  System disk
 Copy code

SSH Connect the software to use FinalShell, The effect picture after connection is as follows ：

Check the system version information .

cat /etc/redhat-release
 Copy code

When the environment is ready , You can modify it yum Source .

Switch yum From Huawei source

CentOS Default access to foreign sources , To speed up, you can switch to Huawei source .

The operation steps are as follows ：

1. install wget

yum install wget -y
 Copy code

2. Back up official source

cd /etc/yum.repos.d/
rename repo repo.old CentOS-*.repo
 Copy code

3. Download Huawei source

wget -O /etc/yum.repos.d/CentOS-Base.repo https://repo.huaweicloud.com/repository/conf/CentOS-7-reg.repo
 Copy code

4. Clear original cache + Generate new cache

yum clean all
yum makecache
 Copy code

You can also view the configuration file at the same time , Refresh cache

yum repolist all
 Copy code

install opengauss

Environment configuration complete , You can enter the installation process , Use the following command to operate .

yum install -y libaio-devel flex bison ncurses-devel glibc.devel patch lsb_release openssl* python3
 Copy code

Status prompt The prompt for successful installation is as follows ：

Switch the system default Python edition

Get into /usr/bin Catalog , Backup Python file

cd /usr/bin
 Copy code

Backup Python file , At the same time establish python3 Soft connection

mv python python.bak
ln -s python3 /usr/bin/python
 Copy code

At this point, the switching is completed , Use python3 The corresponding output has been obtained .

Turn off firewall

Because the official only supports the installation when the firewall is turned off , Therefore, it is necessary to refer to the following settings

[[email protected] yum.repos.d]# systemctl disable firewalld.service
[[email protected] yum.repos.d]# systemctl stop firewalld.service
 Copy code

View firewall status , Use systemctl status firewalld.

close selinux

sed -i 's/SELINUX=enforcing/SELINUX=disabled/g' /etc/selinux/config
 Copy code

See if it's off , Please use the following command ：

cat /etc/selinux/config
 Copy code

Set character set

cat >> /etc/profile <<EOF
> export LANG=en_US.UTF-8
> EOF
 Copy code

You can view the content after setting , The effect is as follows ：

Finally, execute the following command , Make sure the configuration works .

source /etc/profile
 Copy code

Switch off switched memory

swapoff -a
 Copy code

This is because the memory of our current server is too small , Prevent after installation , Database crash .

Create installation users , User groups and software installation directories

Set up user groups

[[email protected] bin]#  groupadd dbgrp
[[email protected] bin]#  useradd -g dbgrp -d /home/omm -m -s /bin/bash omm
[[email protected] bin]#  echo "omm" | passwd --stdin omm
[[email protected] bin]#  mkdir -p /opt/software/openGauss
[[email protected] bin]#  chmod 755 -R /opt/software
[[email protected] bin]#  chown -R omm:dbgrp /opt/software/openGauss
 Copy code

Configuration here , Can pause , Restart the operating system

Set time zone

Operate on the following documents .

rm -fr /etc/localtime
ln -s /usr/share/zoneinfo/Asia/Shanghai /etc/localtime

ll /etc/localtime
 Copy code

close RemoveIPC

modify /etc/systemd/logind.conf In the document RemoveIPC Parameter is no.

Save use wq!.

modify /usr/lib/systemd/system/systemd-logind.service In file RemoveIPC Parameters , without , Manually replenish the value .

RemoveIPC=no
 Copy code

Set the nic MTU value

Use ifconfig View network card information .

about X86,MTU It's worth recommending 1500; about ARM,MTU It's worth recommending 8192.

ifconfig eth0 mtu 1500
 Copy code

install OpenGauss

Open the software download address ：opengauss.org/zh/download…

After downloading , Upload to the... Created above /opt/software/openGauss directory .

Unzip the file , Use the following command ：

tar -zxvf openGauss-3.0.0-CentOS-64bit-all.tar.gz

tar -zxvf openGauss-3.0.0-CentOS-64bit-om.tar.gz
 Copy code

The directory structure after decompression is ：

Next, continue to configure openGauss Of cluster_config.xml file , The file contains openGauss Server information 、 The installation path 、IP Address 、 Port number, etc .

Copy template to \opt\software\openGauss Under the table of contents , The command is as follows ：

cp /script/gspylib/etc/conf/cluster_config_template.xml /opt/software/openGauss
 Copy code

Change the file name cluster_config.xml.

mv cluster_config_template.xml  cluster_config.xml
 Copy code

Use vim cluster_config.xml Open profile , Then modify the following （ The file should preferably be modified locally , Uploading ）：

Make sure again hostname Agreement .

hostname
cat /etc/hostname
 Copy code

And then modify... Again cluster_config.xml Of documents hostname.

Load environment variables

export LD_LIBRARY_PATH=/opt/software/Gauss/script/gspylib/clib:$LD_LIBRARY_PATH
 Copy code

Create a directory and edit it

mkdir –p /opt/huawei

chmod 777 -R /opt/huawei
 Copy code

Add network kernel parameters

vim /etc/sysctl.conf
 Copy code

Add as follows ：

net.ipv4.tcp_retries1 = 5
net.ipv4.tcp_syn_retries = 5
net.sctp.path_max_retrans = 10
net.sctp.max_init_retransmits = 10
 Copy code

Next entry cd /opt/software/openGauss/script Catalog , Execute the following command to start trying to run everything we configured above .

./gs_preinstall -U omm -G dbgrp -X /opt/software/openGauss/cluster_config.xml
 Copy code

The result is the following error , Follow the error prompt to start the redo process , This is what we will cover in our next blog .

openGauss Database installation process , There are many configuration files that need to be modified , When we learn again , It can be modified continuously , According to the error prompt , Where something goes wrong, change it , This article starts with the basic configuration , In the next blog, we will redo the configuration , See you next .
